Cursor Track

Installation

$ pnpm dlx shadcn@latest add @snapcn/cursor-track

Component code

The exact file shadcn add copies into your project.

Usage

A wrapper. It renders children full-bleed and walks a cursor over them along a path of waypoints, pulsing a ring wherever you say there was a click. For UI sims, and for recordings whose real cursor never made it into the file — most capture tools drop it.

import { CursorTrack } from "@/components/snap-cn/cursor-track";
import { ScreenRecording } from "@/components/snap-cn/screen-recording";

<CursorTrack
  path={[
    { at: 0, x: -0.06, y: 0.86, duration: 6 },
    { at: 8, x: 0.34, y: 0.44, duration: 22, click: true },
    { at: 52, x: 0.68, y: 0.62, duration: 20, click: true },
    { at: 96, x: 0.82, y: 0.28, duration: 18 },
  ]}
>
  <ScreenRecording src="/recordings/checkout.mp4" camera={[]} />
</CursorTrack>;

at is the frame the cursor starts travelling towards the point, absolute rather than relative to the previous waypoint. It then rests there until the next waypoint's at — there is no hold field, the hold is the gap. The first waypoint has nothing to travel from, so it places the cursor and its duration is the fade-up window instead; give it an off-frame x (values outside 0–1 are legal) to have the cursor walk in.

click: true pulses the ring on arrival, at at + duration. To click twice without moving, add a second waypoint at the same point.

path defaults to the demo track so the component is worth looking at with nothing passed; path={[]} renders no cursor at all, i.e. a no-op wrapper.

Composing

Put the recording inside this, not this inside the recording — the cursor has to be the top layer to read as a cursor:

<CursorTrack path={path}>
  <ScreenRecording src="/recordings/checkout.mp4" camera={[]} />
</CursorTrack>

Waypoints are frame coordinates and do not ride an inner <ScreenRecording> camera — a push-in moves the UI under the cursor but not the cursor. Keyframe both, or push in on a shot the cursor is already resting in. speed does not propagate either; pass the same value to every layer.

The cursor itself

arrow is a hand-drawn macOS-style pointer with its hotspot at the tip — an SVG, not an emoji and not a font glyph, because a glyph is whatever face the renderer happens to resolve. It stays readable over arbitrary footage through an outline stroked outside the ink rather than a drop shadow. dot is a touch/tap puck for mobile sims.

color defaults to theme.foreground and outlineColor to theme.background, so passing mode="dark" over dark footage swaps both together. Omit size and the cursor is 3.9% of the frame height, which is what a real one looks like at any crop.

When not to use this

When the recording already has a cursor in it. Two pointers on screen is worse than none, and this component cannot remove the one in your file. Also skip it for anything that is not a click path — travel between waypoints is a straight line on an ease-in-out, which reads as deliberate for a demo and robotic for anything meant to look like a human wandering.
